NAXJET T30/50 Thermal transfer machine

Whether marking simple date and time codes, complex regulatory codes, ingredient lists, or marketing information, Naxjet TTO printers help keep your production lines running at peak performance. Print high-resolution images on flexible packaging, film, and labels while minimizing the downtime and costs associated with production changeovers.

High Performance:

Naxjet T32 printer utilized a 32mm print head, it offers a bigger print head and a powerful print firmware with many useful features to en users in the foods, pharmaceutical, seeds, chemical, insecticides, etc..

This printer most economical printing the 32mm range. it reduces initial investment cost and with a high utilization rate of the

Ribbon, it also help reduces the overall running cost. Together with it stable and reliable high quality print, it achieves a high performance to price ratio.

Large Print area:

Printing area up to 32X180mm, suitable for the printing of ingredients and nutritional information of the products to be packed thus reducing the stocking and printing cost of packing substrate.

Stable and reliable high quality print:

300DPI print head used in the Naxjet T series printer, ensure high quality print. It's able to print complex text and logo on a variety of packing film substrate with print quality close to press printing.

Print Area:321X180mm;

Print Density:300DPI 12dots/mm;

Speed:1-30mm/s (different size, different speed);

Ribbon Size:55mmX600M;

Ribbon Gap:0.5mm and user adjustable;

Software Interface: RS232 Industrial Port/USB Transfer;

Hardware Interface:

 Input: Print Trigger, Encoder; Output: Print, Warning, Fault

User Interface:

Job creation without PC, Self-diagnostic

Warning and fault information

3.5inch touch screen; Two USB input

Print Body:

Image Rotation, Font selection

Support Logo, Chinese Print

Serialize, customized printing

Real time, date, expiry date

Support PC control;

Weight: 6.5kgs

Power/Air Supply:

100-120VAC or 220-240VAC

Max 6.0 bar compressed air or Non-air

Working environment: Temperature:0.40 degree C, Humidity:0.90%

Printing Effects：
